| Printer Specifications | |
| Maximum Print Length | 150 inches |
| Maximum Print Speed | 1” to 4” ips |
| Media Sensors | Moveable reflective and see-through sensor, Label sensor, Cover open sensor, ribbon sensor |
| Print Width | 4.1” (104mm) |
| Resolution | 203 dpi/300 dpi |
| Media Characteristics | |
| Media Thickness | 0.002” (0.06mm)to 0.0075” (0.2mm) |
| Media Types | Continuous, die-cut, tag,fan-fold, black mark |
| Ribbon Characteristics | ID：0.5” (12.7 mm) WIDTH：1.0” (25.4mm) to 4.3” (110mm) ● RIBBON MAX. OD：1.535” (39 mm) ● RIBBON LENGTH：Max. length - 100M ● RIBBON TYPE：Outside coating ribbon |
| Operating Characteristics | |
| Electrical | External universal switching power supply |
| Environmental | OPERATION：5°C ~45°C (40°F~104°F) ● STORAGE：-20°C~50°C (-4°F~122°F) OPERATION：10%~90% non-condensing ● STORAGE：5%~95% non-condensing |
| Fonts/Graphics/Symbologies | |
| Barcode Symbologies | 1D：Code39, Code93, Code128 UCC, Code128 UCC/EAN 128, UPC A, UPC E, UPC Interleaved 2-of-5, Japanese Postnet, Logmars, MSI, MSI-3, 2D：Data Matrix, MaxiCode, PDF417, QR code, auto, Codabar, EAN8, EAN13, Interleaved 2of 5, 2 of 5, EAN-14, German Post Code, Industrial Plessey, Postnet, RSS Aztec, Codablock, Code 49 |
| Fonts and Character Sets | FONT 5 internal expandable bitmap fonts (alpha-numeric) 2 internal expandable bitmap Downloadable soft font, GRAPHICS fonts (numeric only) 4 directions：0, 90, 180, 270 degrees PCX, Direct binary graphic |
| File Name | Link |
| BP4001E_Datasheet | Download |
